Kyocera Turning Insert TCGT2205RA3 PDL010: TLK04610

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TLK04610
$43.24

Kyocera Turning Insert TCGT2205RA3 PDL010, manufacturer part number TLK04610.

Specifications: IC Size: 1/4 in (6.35 mm); Insert Thickness: 1/8 in (3.18 mm); Corner Radius: 0.0080 in (0.20 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8860863; Rake: Positive; Number of Cutting Edges: 3; Cutting Range: Finishing-Medium; Usage Classification: Continuous; Insert Size: 2205; Hand Direction: Right; Insert Style: TCGT; ANSI Designation: TCGT2205RA3PDL010; Chip Breaker Type: A3; ISO Designation: TCGT110302R-A3; Included Angle: 60 degrees; Machining Operations: External Turning; Insert Grade: PDL010; Workpiece Material: Non-Ferrous; Insert Shape: Triangle.

Material: Carbide. Coating/Finish: DLC. Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Right
Material
Carbide
Coating/Finish
DLC
IC Size (Metric)
6.35
Included Angle
60
Corner Radius (Decimal)
0.0080
Insert Style
TCGT
Insert Thickness (Fractional)
1/8
Insert Shape
Triangle
Insert Holding Method
Screw or Clamp
Insert Size
2205
Old Material Number
8860863
Insert Thickness (Metric)
3.18
Machining Operations
External Turning
Rake
Positive
IC Size (Fractional)
1/4
Corner Radius (Metric)
0.20
Number of Cutting Edges
3
Insert Grade
PDL010
Chip Breaker Type
A3
Cutting Range
Finishing-Medium
Usage Classification
Continuous
ISO Designation
TCGT110302R-A3
Workpiece Material
Non-Ferrous
ANSI Designation
TCGT2205RA3PDL010
Pack quantity
10
