Kyocera Turning Insert VNMG332RVC CA115P: TML00257
SKU: KYP-TML00257
Kyocera Turning Insert VNMG332RVC TN620, manufacturer part number TSR07895.
Specifications: IC Size: 3/8 in (9.525 mm); Insert Thickness: 3/16 in (4.76 mm); Corner Radius: 1/32 in (0.80 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8848111; Rake: Negative; Number of Cutting Edges: 4; Cutting Range: Finishing-Medium; Usage Classification: Continuous to Light Interruption; Insert Size: 332; Hand Direction: Right; Insert Style: VNMG; Insert Shape: 35 Degree Diamond; ANSI Designation: VNMG332RVCTN620; Chip Breaker Type: VC; ISO Designation: VNMG160408R-VC; Included Angle: 35 degrees; Machining Operations: Copying, External Turning, Facing, Undercutting; Insert Grade: TN620; Workpiece Material: Steel.
Material: Cermet. Coating/Finish: Uncoated. Series: ISOI. Unit of measure: Inch.
