Kyocera Turning Insert WNGG432TK SW05: TWH08671

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TWH08671
$31.22

Kyocera Turning Insert WNGG432TK SW05, manufacturer part number TWH08671.

Specifications: IC Size: 1/2 in (12.70 mm); Insert Thickness: 3/16 in (4.76 mm); Corner Radius: 1/32 in (0.80 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8834229; Rake: Negative; Number of Cutting Edges: 6; Cutting Range: Medium-Roughing; Usage Classification: Continuous to Light Interruption; Insert Size: 432; Hand Direction: Neutral; Insert Style: WNGG; Insert Shape: 80 Degree Trigon; ANSI Designation: WNGG432TKSW05; Chip Breaker Type: TK; ISO Designation: WNGG080408TK; Included Angle: 80 degrees; Machining Operations: Boring, External Turning, Facing, Internal Facing; Insert Grade: SW05; Workpiece Material: High-Temp Alloy.

Material: Carbide. Coating/Finish: Uncoated. Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Neutral
Material
Carbide
Coating/Finish
Uncoated
Insert Thickness (Fractional)
3/16
Corner Radius (Fractional)
1/32
Included Angle
80
ANSI Designation
WNGG432TKSW05
Insert Style
WNGG
Insert Thickness (Metric)
4.76
Insert Shape
80 Degree Trigon
Insert Holding Method
Screw or Clamp
Insert Size
432
Old Material Number
8834229
Machining Operations
Boring, External Turning, Facing, Internal Facing
Insert Grade
SW05
Rake
Negative
IC Size (Metric)
12.70
Corner Radius (Metric)
0.80
Number of Cutting Edges
6
Workpiece Material
High-Temp Alloy
ISO Designation
WNGG080408TK
Cutting Range
Medium-Roughing
Usage Classification
Continuous to Light Interruption
IC Size (Fractional)
1/2
Chip Breaker Type
TK
Pack quantity
10
PDF 3
https://s3-us-west-2.amazonaws.com/catsy.739/PR13-Series_and_SW05_for_Heat_Resistant_Alloys_W.pdf
