Kyocera Turning Insert WNMG431AH KW10: TWE64431

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TWE64431
$24.65

Kyocera Turning Insert WNMG431AH KW10, manufacturer part number TWE64431.

Specifications: IC Size: 1/2 in (12.70 mm); Insert Thickness: 3/16 in (4.76 mm); Corner Radius: 1/64 in (0.40 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8808400; Rake: Negative; Number of Cutting Edges: 6; Cutting Range: Medium-Roughing; Usage Classification: Continuous to Light Interruption; Insert Size: 431; Hand Direction: Neutral; Insert Style: WNMG; Insert Shape: 80 Degree Trigon; ANSI Designation: WNMG431AHKW10; Chip Breaker Type: AH; ISO Designation: WNMG080404AH; Included Angle: 80 degrees; Machining Operations: Boring, External Turning, Facing, Internal Facing; Insert Grade: KW10; Workpiece Material: Non-Ferrous, High-Temp Alloy, Cast Iron.

Material: Carbide. Coating/Finish: Uncoated. Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Neutral
Material
Carbide
Coating/Finish
Uncoated
IC Size (Metric)
12.70
Corner Radius (Fractional)
1/64
Included Angle
80
ANSI Designation
WNMG431AHKW10
Insert Style
WNMG
Insert Thickness (Metric)
4.76
Insert Shape
80 Degree Trigon
Insert Holding Method
Screw or Clamp
Insert Size
431
Old Material Number
8808400
Machining Operations
Boring, External Turning, Facing, Internal Facing
Insert Grade
KW10
Rake
Negative
Insert Thickness (Fractional)
3/16
Corner Radius (Metric)
0.40
Number of Cutting Edges
6
Workpiece Material
Non-Ferrous, High-Temp Alloy, Cast Iron
ISO Designation
WNMG080404AH
Cutting Range
Medium-Roughing
Usage Classification
Continuous to Light Interruption
IC Size (Fractional)
1/2
Chip Breaker Type
AH
Pack quantity
10
