Kyocera Turning Insert WPMT2151GP CA025P: TMH00533

Kyocera Turning Insert WPMT2151GP CA025P, manufacturer part number TMH00533.

Specifications: IC Size: 1/4 in (6.35 mm); Insert Thickness: 3/32 in (2.38 mm); Corner Radius: 1/64 in (0.40 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8861910; Rake: Positive; Number of Cutting Edges: 3; Cutting Range: Finishing; Usage Classification: Continuous to Light Interruption; Insert Size: 2151; Hand Direction: Neutral; Insert Style: WPMT; Insert Shape: 80 Degree Trigon; ANSI Designation: WPMT2151GPCA025P; Chip Breaker Type: GP; ISO Designation: WPMT110204GP; Included Angle: 80 degrees; Machining Operations: Boring; Insert Grade: CA025P; Workpiece Material: Steel; Coating Process: CVD.

Material: Carbide. Coating/Finish: TiCN/Al2O3/TiN. Series: ISOI. Unit of measure: Inch.
