YG-1 Spiral Flute Tap: M5 x 0.8, D4, Steam Oxide, HSS, TA284S

YG-1

No reviews yet Write a Review
SKU:
YG1-TA284S
$22.88

YG-1 spiral flute tap for steel, stainless steel, cast iron and non-ferrous metals, 40 degree helix, square shank. HSS, steam oxide finish. Manufacturer part number TA284S.

Specifications

Unit of Measure
Metric
Shank Type
Square
Overall Length (Decimal)
2.7560
Material
HSS
Coating/Finish
Steam Oxide
Shank Diameter (Decimal)
0.1940
Shank Diameter (Metric)
4.93
Overall Length (Metric)
70.00
Helix Angle
40 degrees
Thread Standard
M
Thread Size
M5 x 0.8
LxD Ratio
2.5xD
Thread Limit
D4
Thread Pitch (mm)
0.80
Blank Standard
DIN/ANSI
Chamfer Length
2P-3P
Workpiece Material
Steel, Stainless Steel, Cast Iron, Non-Ferrous
Drill Size (Decimal)
0.1682
Drill Size (Metric)
4.27
Square Length (Decimal)
0.2500
Square Length (Metric)
6.35
Square Size (Decimal)
0.1520
Square Size (Metric)
3.86
Thread Length (Decimal)
0.3540
Thread Length (Metric)
8.99
Usable Length (Decimal)
0.9330
Usable Length (Metric)
23.70
