SGS Ball End Mill: .050" Dia, 1/4" LOC, 2-1/2" OAL, 3 Flute, Bright/Uncoated, Solid Carbide, 01509

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-01509
$38.30

SGS M3BL ball end mill for steel, stainless steel, cast iron, non-ferrous metals and high-temp alloys, 3 flutes, 30 degree helix, spiral flutes, center cutting, straight shank, external coolant. Solid carbide, bright/uncoated. Manufacturer part number 01509.

Specifications

Series
M3BL
Unit of Measure
Inch
Length of Cut (Decimal)
0.2500
Overall Length (Decimal)
2.5000
Number of Flutes
3
Shank Type
Straight
Shank Length (Decimal)
2.2500
Hand Direction
Right
Material
Solid Carbide
Coating/Finish
Bright/Uncoated
Cutting Diameter (Metric)
1.27
Length of Cut (Metric)
6.35
Length of Cut (Fractional)
1/4
Shank Diameter (Metric)
3.18
Shank Diameter (Fractional)
1/8
Overall Length (Metric)
63.50
Overall Length (Fractional)
2-1/2
Flute Type
Spiral
Helix Angle
30 degrees
Size System
Decimal
Shank Diameter (Decimal)
0.1250
Secondary Workpiece Material
Hardened Steel
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0010
Cutting Diameter Tolerance (Metric)
+0.000/-0.025
Chip Breaker
No
Corner Radius Tolerance (Decimal)
+0.0003/-0.0000
Corner Radius Tolerance (Metric)
+0.008/-0.000
Coolant Option
External Coolant
End Type
Ball
LxD Ratio
5xD
Profile Angle
15 degrees
Shank Length (Fractional)
2-1/4
Rake
Positive
Variable Helix
No
Center Cutting
Yes
Shank Length (Metric)
57.15
Cutting Diameter (Decimal)
0.0500
Helix Direction
Right
Length Type
Long
Shank Tolerance
h6
Workpiece Material
Steel, Stainless Steel, Cast Iron, Non-Ferrous, High-Temp Alloy
SGS Ball End Mill: .050" Dia, 1/4" LOC, 2-1/2" OAL, 3 Flute, Bright/Uncoated, Solid Carbide, 01509
$38.30
