SGS Ball End Mill: .055" Dia, .083" LOC, 3" OAL, 1-3/8" Reach, 3 Flute, Bright/Uncoated, Solid Carbide, 09486

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-09486
$63.23

SGS M3B ball end mill for steel, stainless steel, cast iron, non-ferrous metals and high-temp alloys, 3 flutes, 30 degree helix, spiral flutes, center cutting, straight shank, external coolant. Solid carbide, bright/uncoated. Manufacturer part number 09486.

Specifications

Series
M3B
Unit of Measure
Inch
Length of Cut (Decimal)
0.0830
Overall Length (Decimal)
3.0000
Number of Flutes
3
Shank Type
Straight
Size System
Decimal
Hand Direction
Right
Material
Solid Carbide
Coating/Finish
Bright/Uncoated
Cutting Diameter (Metric)
1.40
Length of Cut (Metric)
2.11
Shank Diameter (Metric)
3.18
Shank Diameter (Fractional)
1/8
Overall Length (Metric)
76.20
Overall Length (Fractional)
3
Flute Type
Spiral
Helix Angle
30 degrees
End Type
Ball
Shank Diameter (Decimal)
0.1250
Secondary Workpiece Material
Hardened Steel
Reach (Decimal)
1.3750
Reach (Metric)
34.93
Reach (Fractional)
1-3/8
Neck Diameter (Decimal)
0.0517
Neck Diameter (Metric)
1.31
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0010
Cutting Diameter Tolerance (Metric)
+0.000/-0.025
Rake
Positive
Corner Radius Tolerance (Decimal)
+0.0003/-0.0000
Corner Radius Tolerance (Metric)
+0.008/-0.000
Coolant Option
External Coolant
Shank Tolerance
h6
Length Type
Long Reach Neck
Profile Angle
15 degrees
Helix Direction
Right
Workpiece Material
Steel, Stainless Steel, Cast Iron, Non-Ferrous, High-Temp Alloy
Variable Helix
No
Center Cutting
Yes
Chip Breaker
No
Reach Multiple
25xD
Cutting Diameter (Decimal)
0.0550
LxD Ratio
1.5xD
