SGS Ball End Mill: .060" Dia, .720" LOC, 2-1/2" OAL, 3 Flute, AlTiN (Ti-NAMITE-A), Solid Carbide, 04522

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-04522
$119.22

SGS M3BX ball end mill for steel, stainless steel, cast iron, non-ferrous metals and high-temp alloys, 3 flutes, 30 degree helix, spiral flutes, center cutting, straight shank, external coolant. Solid carbide, AlTiN coating. Manufacturer part number 04522.

Specifications

Series
M3BX
Unit of Measure
Inch
Length of Cut (Decimal)
0.7200
Overall Length (Decimal)
2.5000
Number of Flutes
3
Shank Type
Straight
Shank Length (Decimal)
1.7800
Hand Direction
Right
Material
Solid Carbide
Coating/Finish
AlTiN
Cutting Diameter (Metric)
1.52
Length of Cut (Metric)
18.29
Shank Diameter (Metric)
3.18
Shank Diameter (Fractional)
1/8
Overall Length (Metric)
63.50
Overall Length (Fractional)
2-1/2
Flute Type
Spiral
Helix Angle
30 degrees
Helix Direction
Right
Shank Diameter (Decimal)
0.1250
Secondary Workpiece Material
Hardened Steel
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0010
Cutting Diameter Tolerance (Metric)
+0.000/-0.025
End Type
Ball
Corner Radius Tolerance (Decimal)
+0.0003/-0.0000
Corner Radius Tolerance (Metric)
+0.008/-0.000
Coolant Option
External Coolant
LxD Ratio
12xD
Rake
Positive
Profile Angle
15 degrees
Shank Length (Metric)
45.21
Shank Tolerance
h6
Variable Helix
No
Center Cutting
Yes
Size System
Decimal
Cutting Diameter (Decimal)
0.0600
Chip Breaker
No
Length Type
Extra Long
Workpiece Material
Steel, Stainless Steel, Cast Iron, Non-Ferrous, High-Temp Alloy
SGS Ball End Mill: .060" Dia, .720" LOC, 2-1/2" OAL, 3 Flute, AlTiN (Ti-NAMITE-A), Solid Carbide, 04522
$119.22
