SGS Square End Mill: .085" Dia, .255" LOC, 2-1/2" OAL, 1.020" Reach, 2 Flute, Bright/Uncoated, Solid Carbide, 09390

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-09390
$52.39

SGS M2S square end mill for steel, stainless steel, cast iron, non-ferrous metals and high-temp alloys, 2 flutes, 30 degree helix, spiral flutes, center cutting, straight shank, external coolant. Solid carbide, bright/uncoated. Manufacturer part number 09390.

Specifications

Series
M2S
Unit of Measure
Inch
Length of Cut (Decimal)
0.2550
Overall Length (Decimal)
2.5000
Size System
Decimal
Number of Flutes
2
Shank Type
Straight
Helix Direction
Right
Hand Direction
Right
Material
Solid Carbide
Coating/Finish
Bright/Uncoated
Cutting Diameter (Metric)
2.16
Length of Cut (Metric)
6.48
Shank Diameter (Metric)
3.18
Shank Diameter (Fractional)
1/8
Overall Length (Metric)
63.50
Overall Length (Fractional)
2-1/2
Flute Type
Spiral
Helix Angle
30 degrees
Reach Multiple
12xD
Cutting Diameter (Decimal)
0.0850
Rake
Positive
Shank Tolerance
h6
Shank Diameter (Decimal)
0.1250
Secondary Workpiece Material
Hardened Steel
Reach (Decimal)
1.0200
Reach (Metric)
25.91
Neck Diameter (Decimal)
0.0799
Neck Diameter (Metric)
2.03
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0010
Cutting Diameter Tolerance (Metric)
+0.000/-0.025
Workpiece Material
Steel, Stainless Steel, Cast Iron, Non-Ferrous, High-Temp Alloy
Coolant Option
External Coolant
End Type
Square
Profile Angle
15 degrees
LxD Ratio
3xD
Variable Helix
No
Center Cutting
Yes
Chip Breaker
No
Length Type
Long Reach Neck
