SGS Square End Mill: .090" Dia, .270" LOC, 2" OAL, .720" Reach, 3 Flute, AlTiN (Ti-NAMITE-A), Solid Carbide, 04286

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-04286
$69.12

SGS M3S square end mill for steel, stainless steel, cast iron, non-ferrous metals and high-temp alloys, 3 flutes, 30 degree helix, spiral flutes, center cutting, straight shank, external coolant. Solid carbide, AlTiN coating. Manufacturer part number 04286.

Specifications

Series
M3S
Unit of Measure
Inch
Length of Cut (Decimal)
0.2700
Overall Length (Decimal)
2.0000
Shank Length (Decimal)
1.2800
Number of Flutes
3
Shank Type
Straight
Shank Length (Metric)
32.51
Hand Direction
Right
Material
Solid Carbide
Coating/Finish
AlTiN
Cutting Diameter (Metric)
2.29
Length of Cut (Metric)
6.86
Shank Diameter (Metric)
3.18
Shank Diameter (Fractional)
1/8
Overall Length (Metric)
50.80
Overall Length (Fractional)
2
Flute Type
Spiral
Helix Angle
30 degrees
Reach Multiple
8xD
Cutting Diameter (Decimal)
0.0900
End Type
Square
LxD Ratio
3xD
Shank Diameter (Decimal)
0.1250
Secondary Workpiece Material
Hardened Steel
Reach (Decimal)
0.7200
Reach (Metric)
18.29
Neck Diameter (Decimal)
0.0846
Neck Diameter (Metric)
2.15
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0010
Cutting Diameter Tolerance (Metric)
+0.000/-0.025
Shank Tolerance
h6
Coolant Option
External Coolant
Size System
Decimal
Length Type
Long Reach Neck
Workpiece Material
Steel, Stainless Steel, Cast Iron, Non-Ferrous, High-Temp Alloy
Profile Angle
15 degrees
Helix Direction
Right
Variable Helix
No
Center Cutting
Yes
Chip Breaker
No
Rake
Positive
