SGS 1/2" Dia, 3 Flute, Ball Nose End Mill - 35010

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-35010
$365.12
SGS 1/2" Dia, 5/8" LOC, 2-1/4" Reach, 1/2" Shank Dia, 3 Flute, 38 Degree Helix, Ti-NAMITE-B (TIB2) Coated, Series 43LB, S-Carb, Ball Nose End Mill - 35010

Specifications

Series
43LB
Unit of Measure
Fractional
Length of Cut
5/8 Inch
Shank Size
1/2 Inch
Number Of Flutes
3
Shank Type
Straight
Overall Length
4 Inch
Cutting Direction
Right
Material
Solid Carbide
Coating/Finish
Ti-NAMITE-B (TIB2)
Cutting Diameter (Decimal)
0.50
Cutting Diameter (Metric)
12.70
Length of Cut (Decimal)
0.63
Length of Cut (Metric)
15.88
Shank Diameter (Decimal)
0.50
Shank Diameter (Metric)
12.70
Overall Length (Decimal)
4
Overall Length (Metric)
101.60
Flute Type
Spiral
Helix Angle
38 degrees
Primary Workpiece Material
(N) Non-Ferrous Materials
Secondary Workpiece Material
Plastics & Composites
Reach (Decimal)
2.25
Reach (Metric)
57.15
Reach (Fractional)
2-1/4
Neck Diameter (Decimal)
0.48
Neck Diameter (Metric)
12.19
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.00043
Cutting Diameter Tolerance (Metric)
+0.000/-0.011
Shank Diameter Tolerance (ISO)
h6
Corner Radius Tolerance (Decimal)
+0.0005/-0.0005
Corner Radius Tolerance (Metric)
+0.013/-0.013
Coolant Option
External Coolant
Additional Geometry
Right Hand Cut Direction (RHC)
Rake Angle
Positive
High Performance
Yes
Weldon Flat
No
Variable Helix
No
Center Cutting
Yes
Type
S-Carb
Cutting Diameter
1/2 Inch
SGS 1/2" Dia, 3 Flute, Ball Nose End Mill - 35010
$365.12
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
