SGS 1/2" Dia, 4 Flute, Ball Nose End Mill - 38492

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-38492
$345.26
SGS 1/2" Dia, 1" LOC, 2-1/4" Reach, 1/2" Shank Dia, 4 Flute, 35-38 Degree Helix, Ti-NAMITE-X (TX) Coated, Series ZPB, Z-Carb-AP, Ball Nose End Mill - 38492

Specifications

Series
ZPB
Unit of Measure
Fractional
Length of Cut
1 Inch
Shank Size
1/2 Inch
Number Of Flutes
4
Shank Type
Straight
Overall Length
6 Inch
Cutting Direction
Right
Material
Solid Carbide
Coating/Finish
Ti-NAMITE-X (TX)
Cutting Diameter (Decimal)
0.50
Cutting Diameter (Metric)
12.70
Length of Cut (Decimal)
1
Length of Cut (Metric)
25.40
Shank Diameter (Decimal)
0.50
Shank Diameter (Metric)
12.70
Overall Length (Decimal)
6
Overall Length (Metric)
152.40
Flute Type
Spiral
Helix Angle
35-38 degrees
Primary Workpiece Material
"(P) Steel, (M) Stainless Steel, (K) Cast Iron, (S) High Temp Alloy"
Secondary Workpiece Material
(H) Hardened Materials
Reach (Decimal)
2.25
Reach (Metric)
57.15
Reach (Fractional)
2-1/4
Neck Diameter (Decimal)
0.48
Neck Diameter (Metric)
12.19
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0020
Cutting Diameter Tolerance (Metric)
+0.000/-0.050
Shank Diameter Tolerance (ISO)
h6
Corner Radius Tolerance (Decimal)
+0.0000/-0.0010
Corner Radius Tolerance (Metric)
+0.000/-0.025
Coolant Option
External Coolant
Additional Geometry
Right Hand Cut Direction (RHC)
Rake Angle
Variable
High Performance
Yes
Weldon Flat
No
Variable Helix
Yes
Center Cutting
Yes
Cutting Diameter
1/2 Inch
SGS 1/2" Dia, 4 Flute, Ball Nose End Mill - 38492
$345.26
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
