SGS Corner Radius End Mill: 1/2" Dia, 1" LOC, 3" OAL, .060" Corner Radius, 4 Flute, TiCN (Ti-NAMITE-C), Solid Carbide, 36116

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-36116
$346.76

SGS Series 61 corner radius end mill for steel and cast iron, 4 flutes, 30 degree helix, spiral flutes, center cutting, Weldon flat shank, external coolant. Solid carbide, TiCN coating. Manufacturer part number 36116.

Specifications

Series
61
Unit of Measure
Inch
Shank Diameter (Fractional)
1/2
Length of Cut (Fractional)
1
Number of Flutes
4
Shank Type
Weldon Flat
Overall Length (Fractional)
3
Material
Solid Carbide
Coating/Finish
TiCN
Cutting Diameter (Decimal)
0.5000
Cutting Diameter (Metric)
12.70
Length of Cut (Decimal)
1.0000
Length of Cut (Metric)
25.40
Shank Diameter (Decimal)
0.5000
Shank Diameter (Metric)
12.70
Overall Length (Decimal)
3.0000
Overall Length (Metric)
76.20
Flute Type
Spiral
Helix Angle
30 degrees
Cutting Diameter (Fractional)
1/2
Secondary Workpiece Material
Hardened Steel
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0040
Cutting Diameter Tolerance (Metric)
+0.000/-0.100
Shank Length (Metric)
50.80
Corner Radius Tolerance (Decimal)
+0.0050/-0.0050
Corner Radius Tolerance (Metric)
+0.127/-0.127
Coolant Option
External Coolant
Size System
Fractional
Helix Direction
Right
Hand Direction
Right
End Type
Corner Radius
Variable Helix
No
Center Cutting
Yes
Chip Breaker
Yes
Type
Coarse Pitch
Shank Length (Decimal)
2.0000
Corner Radius (Decimal)
0.0600
Corner Radius (Metric)
1.52
Length Type
Stub
Performance Class
General Purpose
Rake
Positive
Shank Length (Fractional)
2
Shank Tolerance
h6
Workpiece Material
Steel, Cast Iron
SGS Corner Radius End Mill: 1/2" Dia, 1" LOC, 3" OAL, .060" Corner Radius, 4 Flute, TiCN (Ti-NAMITE-C), Solid Carbide, 36116
$346.76
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
