SGS Square End Mill: 1" Dia, 2-1/4" LOC, 5" OAL, 2 Flute, TiN (Ti-NAMITE), Solid Carbide, 31824

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-31824
$1,146.42

SGS L3S square end mill for steel, stainless steel, cast iron, non-ferrous metals and high-temp alloys, 2 flutes, 30 degree helix, spiral flutes, center cutting, straight shank, external coolant. Solid carbide, TiN coating. Manufacturer part number 31824.

Specifications

Series
L3S
Unit of Measure
Inch
Shank Diameter (Fractional)
1
Length of Cut (Fractional)
2-1/4
Overall Length (Fractional)
5
Number of Flutes
2
Shank Type
Straight
Shank Length (Decimal)
1.9000
Hand Direction
Right
Material
Solid Carbide
Coating/Finish
TiN
Cutting Diameter (Decimal)
1.0000
Cutting Diameter (Metric)
25.40
Length of Cut (Decimal)
2.2500
Length of Cut (Metric)
57.15
Shank Diameter (Decimal)
1.0000
Shank Diameter (Metric)
25.40
Overall Length (Decimal)
5.0000
Overall Length (Metric)
127.00
Flute Type
Spiral
Helix Angle
30 degrees
Size System
Fractional
Cutting Diameter (Fractional)
1
Secondary Workpiece Material
Hardened Steel
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0020
Cutting Diameter Tolerance (Metric)
+0.000/-0.050
End Type
Square
Coolant Option
External Coolant
Shank Length (Metric)
48.26
Performance Class
General Purpose
Rake
Positive
Shank Tolerance
h6
Workpiece Material
Steel, Stainless Steel, Cast Iron, Non-Ferrous, High-Temp Alloy
Variable Helix
No
Center Cutting
Yes
Chip Breaker
No
Helix Direction
Right
Length Type
Standard
