Unit of Measure
Fractional
Shank Type
Weldon (Drive Flat)
Coating/Finish
Ti-NAMITE-A (AlTiN)
Cutting Diameter (Decimal)
1
Cutting Diameter (Metric)
25.40
Length of Cut (Decimal)
1.75
Length of Cut (Metric)
44.45
Shank Diameter (Decimal)
1
Shank Diameter (Metric)
25.40
Overall Length (Decimal)
4
Overall Length (Metric)
101.60
Primary Workpiece Material
"(P) Steel, (K) Cast Iron"
Secondary Workpiece Material
(H) Hardened Materials
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0040
Cutting Diameter Tolerance (Metric)
+0.000/-0.100
Shank Diameter Tolerance (ISO)
h6
Corner Radius Tolerance (Decimal)
+0.0050/-0.0050
Corner Radius Tolerance (Metric)
+0.127/-0.127
Coolant Option
External Coolant
Additional Geometry
Chip Breaker / Right Hand Cut Direction (RHC)
Corner Radius (Decimal)
0.06
Corner Radius (Metric)
1.52
