Shank Diameter (Fractional)
1
Length of Cut (Fractional)
1-1/4
Overall Length (Fractional)
6
Coating/Finish
Ti-NAMITE-X
Cutting Diameter (Decimal)
1.0000
Cutting Diameter (Metric)
25.40
Length of Cut (Decimal)
1.2500
Length of Cut (Metric)
31.75
Shank Diameter (Decimal)
1.0000
Shank Diameter (Metric)
25.40
Overall Length (Decimal)
6.0000
Overall Length (Metric)
152.40
Cutting Diameter (Fractional)
1
Secondary Workpiece Material
Hardened Steel
Neck Diameter (Decimal)
0.9500
Neck Diameter (Metric)
24.13
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0020
Cutting Diameter Tolerance (Metric)
+0.000/-0.050
Shank Length (Metric)
66.68
Corner Radius Tolerance (Decimal)
+0.0000/-0.0020
Corner Radius Tolerance (Metric)
+0.000/-0.050
Coolant Option
External Coolant
Shank Length (Decimal)
2.6250
Corner Radius (Decimal)
0.1200
Corner Radius (Metric)
3.05
Length Type
Long Reach Neck
Maximum Workpiece Hardness
45 HRC
Performance Class
High Performance
Shank Length (Fractional)
2-5/8
Workpiece Material
Steel, Stainless Steel, Cast Iron, High-Temp Alloy
