SGS 10.80mm Dia, 145 Degree Point, Solid Carbide Drill - 64182

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-64182
$646.03
SGS 10.80mm Dia, 145 Degree Point, 12.00mm Shank Dia, 118.00mm OAL, 2 Flute, 5xD, Ti-NAMITE-A (AlTiN) Coated, Series 135L, Hi-PerCarb 135, Solid Carbide Drill - 64182

Specifications

Series
135L
Unit of Measure
Metric
Diameter
10.80 mm
Shank Size
12 mm
Overall Length
118 mm
Cutting Direction
Right
Material
Solid Carbide
Cutting Diameter (Decimal)
0.43
Shank Diameter (Decimal)
0.48
Overall Length (Decimal)
4.65
Flute Type
Spiral
Helix Angle
32 degrees
Primary Workpiece Material
"(P) Steel, (M) Stainless Steel, (H) Hardened Materials"
Secondary Workpiece Material
(K) Cast Iron|(N) Non-Ferrous Materials|(S) High Temp Alloy
Cutting Diameter Tolerance (Decimal)
+.00028 / +.00098
Cutting Diameter Tolerance (Metric)
+.0071 / +.0251
Shank Diameter Tolerance (ISO)
h6
Coolant Option
External Coolant
Coating Description
Ti-NAMITE-A (AlTiN)
Additional Geometry
Right Hand Cut Direction (RHC)
High Performance
Yes
Weldon Flat
No
Variable Helix
No
Center Cutting
No
Chip Breaker
No
Point Angle
145 degrees
Flute Length (Decimal)
2.80
Number of Margins
4
Flute Length
71 mm
Usable Length (Decimal)
2.21
Usable Length (Metric)
56
Self Centering
Yes
Length Of Cut
5 x D
SGS 10.80mm Dia, 145 Degree Point, Solid Carbide Drill - 64182
$646.03
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
