SGS Square End Mill: 15/32" Dia, 1" LOC, 3" OAL, 4 Flute, TX (Ti-NAMITE-X), Solid Carbide, 36430

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-36430
$211.18

SGS Z1S square end mill for steel, stainless steel, cast iron and high-temp alloys, 4 flutes, variable helix, spiral flutes, center cutting, straight shank, external coolant. Solid carbide, Ti-NAMITE-X coating. Manufacturer part number 36430.

Specifications

Series
Z1S
Unit of Measure
Inch
Shank Diameter (Fractional)
1/2
Length of Cut (Fractional)
1
Overall Length (Fractional)
3
Number of Flutes
4
Shank Type
Straight
Shank Length (Decimal)
2.0000
Hand Direction
Right
Material
Solid Carbide
Coating/Finish
Ti-NAMITE-X
Cutting Diameter (Decimal)
0.4688
Cutting Diameter (Metric)
11.91
Length of Cut (Decimal)
1.0000
Length of Cut (Metric)
25.40
Shank Diameter (Decimal)
0.5000
Shank Diameter (Metric)
12.70
Overall Length (Decimal)
3.0000
Overall Length (Metric)
76.20
Flute Type
Spiral
Helix Angle
35-38 degrees
Shank Length (Metric)
50.80
Cutting Diameter (Fractional)
15/32
Secondary Workpiece Material
Hardened Steel
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0020
Cutting Diameter Tolerance (Metric)
+0.000/-0.050
Helix Direction
Right
Coolant Option
External Coolant
Shank Length (Fractional)
2
End Type
Square
Performance Class
High Performance
Rake
Variable
Shank Tolerance
h6
Variable Helix
Yes
Center Cutting
Yes
Chip Breaker
No
Length Type
Standard
Size System
Fractional
Workpiece Material
Steel, Stainless Steel, Cast Iron, High-Temp Alloy
SGS Square End Mill: 15/32" Dia, 1" LOC, 3" OAL, 4 Flute, TX (Ti-NAMITE-X), Solid Carbide, 36430
$211.18
