SGS Ball End Mill: 20.00mm Dia, 45.00mm LOC, 130.00mm OAL, 2 Flute, Bright/Uncoated, Solid Carbide, 43909

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-43909
$1,133.09

SGS 59B ball end mill for steel, stainless steel, cast iron, non-ferrous metals and high-temp alloys, 2 flutes, 25 degree helix, spiral flutes, center cutting, straight shank, external coolant. Solid carbide, bright/uncoated. Manufacturer part number 43909.

Specifications

Series
59B
Unit of Measure
Metric
Shank Diameter (Metric)
20.00
Length of Cut (Metric)
45.00
Number of Flutes
2
Shank Type
Straight
Overall Length (Metric)
130.00
Hand Direction
Right
Material
Solid Carbide
Coating/Finish
Bright/Uncoated
Cutting Diameter (Decimal)
0.7874
Length of Cut (Decimal)
1.7717
Shank Diameter (Decimal)
0.7874
Overall Length (Decimal)
5.1181
Flute Type
Spiral
Helix Angle
25 degrees
Cutting Diameter (Metric)
20.00
Secondary Workpiece Material
Hardened Steel
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0020
Cutting Diameter Tolerance (Metric)
+0.000/-0.050
Size System
Metric
Corner Radius Tolerance (Decimal)
+0.0000/-0.0010
Corner Radius Tolerance (Metric)
+0.000/-0.025
Coolant Option
External Coolant
Helix Direction
Right
Chip Breaker
No
End Type
Ball
Performance Class
General Purpose
Variable Helix
No
Center Cutting
Yes
Shank Length (Decimal)
3.3480
Length Type
Standard
Rake
Positive
Shank Length (Metric)
85.04
Shank Tolerance
h6
Workpiece Material
Steel, Stainless Steel, Cast Iron, Non-Ferrous, High-Temp Alloy
