SGS 20.00mm Dia, 2 Flute, Ball Nose End Mill - 44579

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-44579
$714.59
SGS 20.00mm Dia, 37.32mm LOC, 20.00mm Shank Dia, 2 Flute, 35 Degree Helix, Uncoated, Series 47MB, S-Carb, Ball Nose End Mill - 44579

Specifications

Series
47MB
Unit of Measure
Metric
Length of Cut
37.32 mm
Shank Size
20 mm
Number Of Flutes
2
Shank Type
Straight
Overall Length
104 mm
Cutting Direction
Right
Material
Solid Carbide
Coating/Finish
Uncoated
Cutting Diameter (Decimal)
0.79
Length of Cut (Decimal)
1.47
Shank Diameter (Decimal)
0.79
Overall Length (Decimal)
4.10
Flute Type
Spiral
Helix Angle
35 degrees
Primary Workpiece Material
(N) Non-Ferrous Materials
Secondary Workpiece Material
Plastics & Composites
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.00051
Cutting Diameter Tolerance (Metric)
+0.000/-0.013
Shank Diameter Tolerance (ISO)
h6
Corner Radius Tolerance (Decimal)
+0.0005/-0.0005
Corner Radius Tolerance (Metric)
+0.013/-0.013
Coolant Option
External Coolant
Additional Geometry
Right Hand Cut Direction (RHC)
Rake Angle
Positive
High Performance
Yes
Weldon Flat
No
Variable Helix
No
Center Cutting
Yes
Type
S-Carb
Cutting Diameter
20 mm
SGS 20.00mm Dia, 2 Flute, Ball Nose End Mill - 44579
$714.59
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
