SGS #26, 118 Degree Point, Solid Carbide Drill - 57139

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-57139
$65.46
SGS #26, 118 Degree Point, 0.1470" Shank Dia, 2-1/2" OAL, 2 Flute, 5xD, Ti-NAMITE-A (AlTiN) Coated, Series 101, Solid Carbide Drill - 57139

Specifications

Series
101
Unit of Measure
Imperial
Diameter
0.15 Inch
Shank Size
0.15 Inch
Overall Length
2.50 Inch
Cutting Direction
Right
Material
Solid Carbide
Cutting Diameter (Metric)
3.73
Shank Diameter (Metric)
3.73
Overall Length (Metric)
63.50
Overall Length (Fractional)
2-1/2
Flute Type
Spiral
Helix Angle
20 degrees
Primary Workpiece Material
"(P) Steel, (M) Stainless Steel, (K) Cast Iron, (N) Non-Ferrous Materials, (S) High Temp Alloy"
Secondary Workpiece Material
(H) Hardened Materials
Cutting Diameter Tolerance (Decimal)
+.00000 / -.00050
Cutting Diameter Tolerance (Metric)
+.0000 / -.0180
Shank Diameter Tolerance (ISO)
h6
Coolant Option
External Coolant
Coating Description
Ti-NAMITE-A (AlTiN)
Additional Geometry
Right Hand Cut Direction (RHC)
High Performance
No
Weldon Flat
No
Variable Helix
No
Center Cutting
No
Chip Breaker
No
Point Angle
118 degrees
Cutting Diameter (Wire)
#26
Flute Length (Metric)
34.93
Flute Length (Fractional)
1-3/8
Number of Margins
2
Flute Length
1.38 Inch
Usable Length (Decimal)
1.11
Usable Length (Metric)
28.18
Usable Length (Fractional)
1-7/64
Length Of Cut
5 x D
SGS #26, 118 Degree Point, Solid Carbide Drill - 57139
$65.46
