SGS 3.00mm Dia, 2 Flute, Router - 90101

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-90101
$66.49
SGS 3.00mm Dia, 13.00mm LOC, 50.00mm OAL, 6.00mm Shank Dia, 2 Flute, 35 Degree Helix, Uncoated, Series 21S, Wood Router Up Cut - 90101

Specifications

Series
21S
Unit of Measure
Metric
Diameter
3 mm
Length of Cut
13 mm
Shank Size
6 mm
Number Of Flutes
2
Shank Type
Straight
Overall Length
50 mm
Cutting Direction
Right
Material
Solid Carbide
Coating/Finish
Uncoated
Cutting Diameter (Decimal)
0.12
Length of Cut (Decimal)
0.52
Shank Diameter (Decimal)
0.24
Overall Length (Decimal)
1.97
Flute Type
Spiral
Helix Angle
35 degrees
End Configuration
Square End
Tool Length
Regular
Primary Workpiece Material
(N) Non-Ferrous Materials
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0030
Cutting Diameter Tolerance (Metric)
+0.000/-0.080
Shank Diameter Tolerance (ISO)
h6
Coolant Option
External Coolant
Rake Angle
Positive
High Performance
No
Weldon Flat
No
Variable Helix
No
Center Cutting
Yes
Chip Breaker
No
Unit (inch/mm)
mm
SGS 3.00mm Dia, 2 Flute, Router - 90101
$66.49
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
