SGS Square End Mill: 3.00mm Dia, 7.00mm LOC, 38.00mm OAL, 2 Flute, Bright/Uncoated, Solid Carbide, 45277

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-45277
$35.51

SGS 52S square end mill for non-ferrous metals, 2 flutes, 30 degree helix, spiral flutes, center cutting, straight shank, external coolant. Solid carbide, bright/uncoated. Manufacturer part number 45277.

Specifications

Series
52S
Unit of Measure
Metric
Cutting Diameter (Metric)
3.00
Shank Diameter (Metric)
3.00
Length of Cut (Metric)
7.00
Number of Flutes
2
Shank Type
Straight
Overall Length (Metric)
38.00
Hand Direction
Right
Material
Solid Carbide
Coating/Finish
Bright/Uncoated
Cutting Diameter (Decimal)
0.1181
Length of Cut (Decimal)
0.2756
Shank Diameter (Decimal)
0.1181
Overall Length (Decimal)
1.4961
Flute Type
Spiral
Helix Angle
30 degrees
Shank Length (Metric)
31.09
Size System
Metric
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0020
Cutting Diameter Tolerance (Metric)
+0.000/-0.050
Helix Direction
Right
Coolant Option
External Coolant
Shank Length (Decimal)
1.2240
End Type
Square
Performance Class
General Purpose
Rake
Positive
Shank Tolerance
h6
Variable Helix
No
Center Cutting
Yes
Chip Breaker
No
Length Type
Standard
Workpiece Material
Non-Ferrous
SGS Square End Mill: 3.00mm Dia, 7.00mm LOC, 38.00mm OAL, 2 Flute, Bright/Uncoated, Solid Carbide, 45277
$35.51
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
