SGS #3, 150 Degree Point, Solid Carbide Drill - 58051

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-58051
$133.57
SGS #3, 150 Degree Point, 0.2130" Shank Dia, 3" OAL, 3 Flute, 5xD, Ti-NAMITE-A (AlTiN) Coated, Series 103, Solid Carbide Drill - 58051

Specifications

Series
103
Unit of Measure
Imperial
Diameter
0.22 Inch
Shank Size
0.22 Inch
Overall Length
3 Inch
Cutting Direction
Right
Material
Solid Carbide
Cutting Diameter (Metric)
5.41
Shank Diameter (Metric)
5.41
Overall Length (Metric)
76.20
Overall Length (Fractional)
3
Flute Type
Spiral
Helix Angle
30 degrees
Primary Workpiece Material
"(P) Steel, (K) Cast Iron, (N) Non-Ferrous Materials"
Secondary Workpiece Material
(H) Hardened Materials
Cutting Diameter Tolerance (Decimal)
+.00000 / -.00050
Cutting Diameter Tolerance (Metric)
+.0000 / -.0127
Shank Diameter Tolerance (ISO)
h6
Coolant Option
External Coolant
Coating Description
Ti-NAMITE-A (AlTiN)
Additional Geometry
Right Hand Cut Direction (RHC)
High Performance
No
Weldon Flat
No
Variable Helix
No
Center Cutting
No
Chip Breaker
No
Point Angle
150 degrees
Cutting Diameter (Wire)
#3
Flute Length (Metric)
44.45
Flute Length (Fractional)
1-3/4
Number of Margins
3
Flute Length
1.75 Inch
Usable Length (Decimal)
1.41
Usable Length (Metric)
35.72
Usable Length (Fractional)
1-13/32
Length Of Cut
5 x D
SGS #3, 150 Degree Point, Solid Carbide Drill - 58051
$133.57
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
