Shank Diameter (Fractional)
3/16
Length of Cut (Fractional)
5/8
Overall Length (Fractional)
2
Coating/Finish
Ti-NAMITE-X
Cutting Diameter (Decimal)
0.1875
Cutting Diameter (Metric)
4.76
Length of Cut (Decimal)
0.6250
Length of Cut (Metric)
15.88
Shank Diameter (Decimal)
0.1875
Shank Diameter (Metric)
4.76
Overall Length (Decimal)
2.0000
Overall Length (Metric)
50.80
Cutting Diameter (Fractional)
3/16
Secondary Workpiece Material
Hardened Steel
Non-Cutting Center Diameter (Decimal)
0.0550
Non-Cutting Center Diameter (Metric)
1.40
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0020
Cutting Diameter Tolerance (Metric)
+0.000/-0.050
Shank Length (Metric)
34.93
Corner Radius Tolerance (Decimal)
+0.0000/-0.0020
Corner Radius Tolerance (Metric)
+0.000/-0.050
Coolant Option
External Coolant
Shank Length (Decimal)
1.3750
Corner Radius (Decimal)
0.0100
Corner Radius (Metric)
0.25
Maximum Workpiece Hardness
45 HRC
Performance Class
High Performance
Shank Length (Fractional)
1-3/8
Workpiece Material
Steel, Stainless Steel, Cast Iron, High-Temp Alloy
