Unit of Measure
Fractional
Cutting Diameter (Decimal)
0.10
Cutting Diameter (Metric)
2.38
Shank Diameter (Decimal)
0.13
Shank Diameter (Metric)
3.18
Overall Length (Decimal)
2
Overall Length (Metric)
50.80
Primary Workpiece Material
"(P) Steel, (M) Stainless Steel, (H) Hardened Materials"
Secondary Workpiece Material
(K) Cast Iron|(N) Non-Ferrous Materials|(S) High Temp Alloy
Cutting Diameter Tolerance (Decimal)
+.00008 / +.00047
Cutting Diameter Tolerance (Metric)
+.0020 / +.0119
Shank Diameter Tolerance (ISO)
h6
Coolant Option
External Coolant
Coating Description
Ti-NAMITE-A (AlTiN)
Additional Geometry
Right Hand Cut Direction (RHC)
Flute Length (Decimal)
0.50
Flute Length (Metric)
12.70
Usable Length (Decimal)
0.44
Usable Length (Metric)
11.11
Usable Length (Fractional)
7/16
