SGS Corner Radius End Mill: 3/4" Dia, 1-7/8" LOC, 4-1/4" OAL, .060" Corner Radius, 4 Flute, TiB2, Solid Carbide, 34025

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-34025
$800.14

SGS APF corner radius end mill for non-ferrous metals, 4 flutes, variable helix, spiral flutes, center cutting, straight shank, internal coolant. Solid carbide, TiB2 coating. Manufacturer part number 34025.

Specifications

Series
APF
Unit of Measure
Inch
Cutting Diameter (Fractional)
3/4
Shank Diameter (Fractional)
3/4
Number of Flutes
4
Shank Type
Straight
Length of Cut (Fractional)
1-7/8
Material
Solid Carbide
Coating/Finish
TiB2
Cutting Diameter (Decimal)
0.7500
Cutting Diameter (Metric)
19.05
Length of Cut (Decimal)
1.8750
Length of Cut (Metric)
47.63
Shank Diameter (Decimal)
0.7500
Shank Diameter (Metric)
19.05
Overall Length (Decimal)
4.2500
Overall Length (Metric)
107.95
Flute Type
Spiral
Helix Angle
38/41 degrees
Shank Length (Decimal)
2.3750
Neck Diameter (Decimal)
0.7280
Neck Diameter (Metric)
18.49
Cutting Diameter Tolerance (Decimal)
-0.0004/-0.0020
Cutting Diameter Tolerance (Metric)
-0.010/-0.050
Shank Length (Fractional)
2-3/8
Corner Radius Tolerance (Decimal)
+0.0000/-0.0012
Corner Radius Tolerance (Metric)
+0.000/-0.030
Coolant Option
Internal Coolant
Shank Length (Metric)
60.33
Size System
Fractional
Helix Direction
Right
Hand Direction
Right
Variable Helix
Yes
Center Cutting
Yes
Chip Breaker
No
Type
S-Carb
Overall Length (Fractional)
4-1/4
Corner Radius (Decimal)
0.0600
Corner Radius (Metric)
1.52
End Type
Corner Radius
Length Type
Standard
Maximum Workpiece Hardness
150 HB
Performance Class
High Performance
Rake
Positive
Shank Tolerance
h6
Workpiece Material
Non-Ferrous
