Shank Diameter (Fractional)
3/4
Length of Cut (Fractional)
1-1/2
Overall Length (Fractional)
6
Coating/Finish
Ti-NAMITE-X
Cutting Diameter (Decimal)
0.7500
Cutting Diameter (Metric)
19.05
Length of Cut (Decimal)
1.5000
Length of Cut (Metric)
38.10
Shank Diameter (Decimal)
0.7500
Shank Diameter (Metric)
19.05
Overall Length (Decimal)
6.0000
Overall Length (Metric)
152.40
Helix Angle
35-38 degrees
Cutting Diameter (Fractional)
3/4
Secondary Workpiece Material
Hardened Steel
Neck Diameter (Decimal)
0.7300
Neck Diameter (Metric)
18.54
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0020
Cutting Diameter Tolerance (Metric)
+0.000/-0.050
Shank Length (Metric)
63.50
Corner Radius Tolerance (Decimal)
+0.0000/-0.0020
Corner Radius Tolerance (Metric)
+0.000/-0.050
Coolant Option
External Coolant
Shank Length (Decimal)
2.5000
Corner Radius (Decimal)
0.0400
Corner Radius (Metric)
1.02
Length Type
Long Reach Neck
Maximum Workpiece Hardness
45 HRC
Performance Class
High Performance
Shank Length (Fractional)
2-1/2
Workpiece Material
Steel, Stainless Steel, Cast Iron, High-Temp Alloy
