Unit of Measure
Fractional
Overall Length
1-1/2 Inch
Cutting Diameter (Decimal)
0.05
Cutting Diameter (Metric)
1.19
Shank Diameter (Decimal)
0.05
Shank Diameter (Metric)
1.19
Shank Diameter (Fractional)
3/64
Overall Length (Decimal)
1.50
Overall Length (Metric)
38.10
Primary Workpiece Material
"(P) Steel, (M) Stainless Steel, (K) Cast Iron, (N) Non-Ferrous Materials, (S) High Temp Alloy"
Secondary Workpiece Material
(H) Hardened Materials
Cutting Diameter Tolerance (Decimal)
+020 / -000
Cutting Diameter Tolerance (Metric)
+51 / -00
Shank Diameter Tolerance (Decimal)
+0.0002 / -0.0000
Shank Diameter Tolerance (Metric)
+0.0051 / -0.0000
Coolant Option
External Coolant
Max. Ream Length
3/4 Inch
Maximum Ream Length (Decimal)
0.75
Maximum Ream Length (Metric)
19.05
Chamfer Angle (a)
45 degrees
