Unit of Measure
Fractional
Overall Length
3-1/2 Inch
Cutting Diameter (Decimal)
0.38
Cutting Diameter (Metric)
9.53
Length of Cut (Decimal)
1.50
Length of Cut (Metric)
38.10
Shank Diameter (Decimal)
0.38
Shank Diameter (Metric)
9.53
Overall Length (Decimal)
3.50
Overall Length (Metric)
88.90
End Configuration
Square End
Primary Workpiece Material
"(P) Steel, (M) Stainless Steel, (K) Cast Iron, (S) High Temp Alloy"
Secondary Workpiece Material
(H) Hardened Materials
Non-Cutting Center Diameter (Decimal)
0.13
Non-Cutting Center Diameter (Metric)
3.22
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0016
Cutting Diameter Tolerance (Metric)
+0.000/-0.040
Shank Diameter Tolerance (ISO)
h6
Shank Diameter Tolerance (Decimal)
+0.0000 / -0.00035
Shank Diameter Tolerance (Metric)
+0.0000 / -0.009
Coolant Option
External Coolant
Coating Description
Ti-NAMITE-A (AlTiN)
Additional Geometry
Right Hand Cut Direction (RHC)
