SGS 4.00mm Dia, 135 Degree Point, 6.00mm Shank Dia, 66.00mm OAL, 2 Flute, 3xD, Coolant-Through, Ti-NAMITE-X (TX) Coated, Series 142P, Hi-PerCarb 142P, Solid Carbide Drill - 66410
Specifications
Cutting Diameter (Decimal)
0.16
Shank Diameter (Decimal)
0.24
Overall Length (Decimal)
2.60
Primary Workpiece Material
"(P) Steel, (N) Non-Ferrous Materials, (H) Hardened Materials"
Secondary Workpiece Material
(M) Stainless Steel|(K) Cast Iron|(S) High Temp Alloy
Cutting Diameter Tolerance (Decimal)
+.00016 / +.00063
Cutting Diameter Tolerance (Metric)
+.0041 / +.0160
Shank Diameter Tolerance (ISO)
h6
Coolant Option
Internal Coolant
Coating Description
Ti-NAMITE-X (TX)
Additional Geometry
Right Hand Cut Direction (RHC)
Flute Length (Decimal)
0.95
Usable Length (Decimal)
0.67
Usable Length (Metric)
17
Point Length (Decimal)
0.04
Point Length (Metric)
0.83
