SGS Ball End Mill: 5/32" Dia, .437" LOC, 2" OAL, 4 Flute, TX (Ti-NAMITE-X), Solid Carbide, 36357

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-36357
$80.82

SGS Z1B ball end mill for steel, stainless steel, cast iron and high-temp alloys, 4 flutes, variable helix, spiral flutes, center cutting, straight shank, external coolant. Solid carbide, Ti-NAMITE-X coating. Manufacturer part number 36357.

Specifications

Series
Z1B
Unit of Measure
Inch
Shank Diameter (Fractional)
3/16
Number of Flutes
4
Shank Type
Straight
Overall Length (Fractional)
2
Hand Direction
Right
Material
Solid Carbide
Coating/Finish
Ti-NAMITE-X
Cutting Diameter (Decimal)
0.1563
Cutting Diameter (Metric)
3.97
Length of Cut (Decimal)
0.4370
Length of Cut (Metric)
11.10
Shank Diameter (Decimal)
0.1875
Shank Diameter (Metric)
4.76
Overall Length (Decimal)
2.0000
Overall Length (Metric)
50.80
Flute Type
Spiral
Helix Angle
35-38 degrees
Cutting Diameter (Fractional)
5/32
Secondary Workpiece Material
Hardened Steel
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0012
Cutting Diameter Tolerance (Metric)
+0.000/-0.030
Size System
Fractional
Corner Radius Tolerance (Decimal)
+0.0000/-0.0006
Corner Radius Tolerance (Metric)
+0.000/-0.015
Coolant Option
External Coolant
Helix Direction
Right
Chip Breaker
No
End Type
Ball
Performance Class
High Performance
Variable Helix
Yes
Center Cutting
Yes
Shank Length (Decimal)
1.5630
Length Type
Standard
Maximum Workpiece Hardness
45 HRC
Rake
Variable
Shank Length (Metric)
39.70
Shank Tolerance
h6
Workpiece Material
Steel, Stainless Steel, Cast Iron, High-Temp Alloy
