Unit of Measure
Fractional
Coating/Finish
Ti-NAMITE-A (AlTiN)
Cutting Diameter (Decimal)
0.63
Cutting Diameter (Metric)
15.88
Length of Cut (Decimal)
1.88
Length of Cut (Metric)
47.63
Shank Diameter (Decimal)
0.63
Shank Diameter (Metric)
15.88
Overall Length (Decimal)
4
Overall Length (Metric)
101.60
Primary Workpiece Material
"(P) Steel, (M) Stainless Steel, (K) Cast Iron, (S) High Temp Alloy"
Secondary Workpiece Material
(H) Hardened Materials
Non-Cutting Center Diameter (Decimal)
0.22
Non-Cutting Center Diameter (Metric)
5.56
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0020
Cutting Diameter Tolerance (Metric)
+0.000/-0.050
Shank Diameter Tolerance (ISO)
h6
Corner Radius Tolerance (Decimal)
+0.0000/-0.0020
Corner Radius Tolerance (Metric)
+0.000/-0.050
Coolant Option
Internal Coolant
Additional Geometry
Chip Breaker / Right Hand Cut Direction (RHC)
Cutting Diameter
5/8 Inch
Corner Radius (Decimal)
0.19
Corner Radius (Metric)
4.83
