SGS Square End Mill: 6.00mm Dia, 13.00mm LOC, 57.00mm OAL, 4 Flute, TX (Ti-NAMITE-X), Solid Carbide, 46360

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-46360
$77.32

SGS Z1MS square end mill for steel, stainless steel, cast iron and high-temp alloys, 4 flutes, variable helix, spiral flutes, center cutting, straight shank, external coolant. Solid carbide, Ti-NAMITE-X coating. Manufacturer part number 46360.

Specifications

Series
Z1MS
Unit of Measure
Metric
Shank Diameter (Metric)
6.00
Length of Cut (Metric)
13.00
Overall Length (Metric)
57.00
Number of Flutes
4
Shank Type
Straight
Shank Length (Decimal)
1.7280
Hand Direction
Right
Material
Solid Carbide
Coating/Finish
Ti-NAMITE-X
Cutting Diameter (Decimal)
0.2362
Length of Cut (Decimal)
0.5118
Shank Diameter (Decimal)
0.2362
Overall Length (Decimal)
2.2441
Flute Type
Spiral
Helix Angle
35-38 degrees
Size System
Metric
Cutting Diameter (Metric)
6.00
Secondary Workpiece Material
Hardened Steel
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0012
Cutting Diameter Tolerance (Metric)
+0.000/-0.030
End Type
Square
Coolant Option
External Coolant
Shank Length (Metric)
43.89
Performance Class
High Performance
Rake
Variable
Shank Tolerance
h6
Workpiece Material
Steel, Stainless Steel, Cast Iron, High-Temp Alloy
Length Type
Standard
Variable Helix
Yes
Center Cutting
Yes
Chip Breaker
No
Helix Direction
Right
Maximum Workpiece Hardness
45 HRC
SGS Square End Mill: 6.00mm Dia, 13.00mm LOC, 57.00mm OAL, 4 Flute, TX (Ti-NAMITE-X), Solid Carbide, 46360
