Unit of Measure
Fractional
Overall Length
4-1/2 Inch
Cutting Diameter (Decimal)
0.44
Cutting Diameter (Metric)
11.11
Shank Diameter (Decimal)
0.44
Shank Diameter (Metric)
11.11
Overall Length (Decimal)
4.50
Overall Length (Metric)
114.30
Primary Workpiece Material
"(P) Steel, (M) Stainless Steel, (K) Cast Iron, (N) Non-Ferrous Materials, (S) High Temp Alloy"
Secondary Workpiece Material
(H) Hardened Materials
Cutting Diameter Tolerance (Decimal)
+.00000 / -.00050
Cutting Diameter Tolerance (Metric)
+.0000 / -.0127
Shank Diameter Tolerance (ISO)
h6
Coolant Option
External Coolant
Coating Description
Uncoated
Additional Geometry
Right Hand Cut Direction (RHC)
Flute Length (Decimal)
2.88
Flute Length (Metric)
73.03
Usable Length (Decimal)
2.30
Usable Length (Metric)
58.34
Usable Length (Fractional)
2-19/64
