SGS 7/16" Dia, 124 Degree Point, Solid Carbide Drill - 54625

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-54625
$348.16
SGS 7/16" Dia, 124 Degree Point, 0.4724" Shank Dia, 4.0157" OAL, 3 Flute, 3xD, Uncoated, Series 131N, Hi-PerCarb 131N, Solid Carbide Drill - 54625

Specifications

Series
131N
Unit of Measure
Fractional
Diameter
7/16 Inch
Cutting Direction
Right
Material
Solid Carbide
Cutting Diameter (Decimal)
0.44
Cutting Diameter (Metric)
11.11
Shank Diameter (Decimal)
0.48
Shank Diameter (Metric)
12
Overall Length (Decimal)
4.02
Overall Length (Metric)
102
Flute Type
Spiral
Helix Angle
30 degrees
Primary Workpiece Material
(N) Non-Ferrous Materials
Secondary Workpiece Material
(K) Cast Iron|(S) High Temp Alloy
Cutting Diameter Tolerance (Decimal)
+.00028 / +.00098
Cutting Diameter Tolerance (Metric)
+.0071 / +.0251
Shank Diameter Tolerance (ISO)
h6
Coolant Option
External Coolant
Coating Description
Uncoated
Additional Geometry
Right Hand Cut Direction (RHC)
High Performance
Yes
Weldon Flat
No
Variable Helix
No
Center Cutting
No
Chip Breaker
No
Point Angle
124 degrees
Flute Length (Decimal)
2.17
Flute Length (Metric)
55
DIN Standard
DIN 6537
Number of Margins
3
Usable Length (Decimal)
1.58
Usable Length (Metric)
40
Self Centering
Yes
Length Of Cut
3 x D
SGS 7/16" Dia, 124 Degree Point, Solid Carbide Drill - 54625
$348.16
