SGS 8.00mm Dia, 3 Flute, Corner Radius End Mill - 44852

Kyocera SGS

No reviews yet Write a Review
SKU:
KYO-44852
$127.74
SGS 8.00mm Dia, 32.00mm LOC, 8.00mm Shank Dia, 1.50mm Radius, 3 Flute, 38 Degree Helix, Ti-NAMITE-B (TIB2) Coated, Series 43ME, S-Carb, Corner Radius End Mill - 44852

Specifications

Series
43ME
Unit of Measure
Metric
Length of Cut
32 mm
Shank Size
8 mm
Number Of Flutes
3
Shank Type
Straight
Overall Length
75 mm
Material
Solid Carbide
Coating/Finish
Ti-NAMITE-B (TIB2)
Cutting Diameter (Decimal)
0.32
Length of Cut (Decimal)
1.26
Shank Diameter (Decimal)
0.32
Overall Length (Decimal)
2.96
Flute Type
Spiral
Helix Angle
38 degrees
Primary Workpiece Material
(N) Non-Ferrous Materials
Secondary Workpiece Material
Plastics & Composites
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.00035
Cutting Diameter Tolerance (Metric)
+0.000/-0.009
Shank Diameter Tolerance (ISO)
h6
Corner Radius Tolerance (Decimal)
+0.0000/-0.0020
Corner Radius Tolerance (Metric)
+0.000/-0.050
Coolant Option
External Coolant
Additional Geometry
Right Hand Cut Direction (RHC)
Rake Angle
Positive
High Performance
Yes
Weldon Flat
No
Variable Helix
No
Center Cutting
Yes
Chip Breaker
No
Type
S-Carb
Cutting Diameter
8 mm
Corner Radius (Decimal)
0.06
Corner Radius
1.50 mm
SGS 8.00mm Dia, 3 Flute, Corner Radius End Mill - 44852
$127.74
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
