Coating/Finish
Ti-NAMITE-X (TX)
Cutting Diameter (Decimal)
0.32
Length of Cut (Decimal)
0.75
Shank Diameter (Decimal)
0.32
Overall Length (Decimal)
2.49
Helix Angle
35-38 degrees
Primary Workpiece Material
"(P) Steel, (M) Stainless Steel, (K) Cast Iron, (S) High Temp Alloy"
Secondary Workpiece Material
(H) Hardened Materials
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0016
Cutting Diameter Tolerance (Metric)
+0.000/-0.040
Shank Diameter Tolerance (ISO)
h6
Corner Radius Tolerance (Decimal)
+0.0000/-0.0008
Corner Radius Tolerance (Metric)
+0.000/-0.020
Coolant Option
External Coolant
Additional Geometry
Flute Spacing Unequal / Right Hand Cut Direction (RHC)
