SGS 8.00mm Dia, 10.00mm LOC, 25.27mm Reach, 8.00mm Shank Dia, 1.00mm Radius, 4 Flute, 42-45 Degree Helix, Ti-NAMITE-X (TX) Coated, Series ZD1M, Z-Carb-MD, Corner Radius End Mill - 46564
Specifications
Coating/Finish
Ti-NAMITE-X (TX)
Cutting Diameter (Decimal)
0.32
Length of Cut (Decimal)
0.40
Shank Diameter (Decimal)
0.32
Overall Length (Decimal)
2.49
Helix Angle
42-45 degrees
Primary Workpiece Material
"(K) Cast Iron, (H) Hardened Materials"
Secondary Workpiece Material
(P) Steel
Neck Diameter (Decimal)
0.30
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0016
Cutting Diameter Tolerance (Metric)
+0.000/-0.040
Shank Diameter Tolerance (ISO)
h6
Corner Radius Tolerance (Decimal)
+0.0000/-0.0020
Corner Radius Tolerance (Metric)
+0.000/-0.050
Coolant Option
External Coolant
Additional Geometry
Flute Spacing Unequal / Right Hand Cut Direction (RHC)
Corner Radius (Decimal)
0.04
