Cutting Diameter (Decimal)
0.32
Length of Cut (Decimal)
0.79
Shank Diameter (Decimal)
0.32
Overall Length (Decimal)
2.96
End Configuration
Chip Breaker (Square)
Primary Workpiece Material
"(P) Steel, (M) Stainless Steel, (K) Cast Iron, (S) High Temp Alloy"
Secondary Workpiece Material
(H) Hardened Materials
Non-Cutting Center Diameter (Decimal)
0.11
Non-Cutting Center Diameter (Metric)
2.71
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0016
Cutting Diameter Tolerance (Metric)
+0.000/-0.040
Shank Diameter Tolerance (ISO)
h6
Shank Diameter Tolerance (Decimal)
+0.0000 / -0.00035
Shank Diameter Tolerance (Metric)
+0.0000 / -0.009
Coolant Option
External Coolant
Coating Description
Ti-NAMITE-M (TM)
Additional Geometry
Chip Breaker / Right Hand Cut Direction (RHC)
