Fullerton Corner Radius End Mill: 3/8" Dia, 1" LOC, 2-1/2" OAL, .030" Corner Radius, 4 Flute, Uncoated, 33721

Fullerton

No reviews yet Write a Review
SKU:
FUL-33721
$53.88

3/8" Dia, 1" LOC, 2-1/2" OAL, .030" Corner Radius Fullerton Corner Radius End Mill, manufacturer part number 33721.

Specifications: Cutting Diameter: 3/8 in (0.3750 in, 9.53 mm); Length of Cut: 1 in (1.0000 in, 25.40 mm); Overall Length: 2-1/2 in (2.5000 in, 63.50 mm); Corner Radius: 0.0300 in (0.76 mm); Shank Diameter: 3/8 in (0.3750 in, 9.53 mm); Number of Flutes: 4; Helix Angle: 30 degrees; Double Ended: No; Length Type: Standard; Coolant Option: External Coolant; End Type: Corner Radius; Hand Direction: Right; Helix Direction: Right.

Coating/Finish: Uncoated. Unit of measure: Inch.

Specifications

Unit of Measure
Inch
Length of Cut (Decimal)
1.0000
Overall Length (Decimal)
2.5000
Double Ended
No
Hand Direction
Right
Cutting Diameter (Metric)
9.53
Length of Cut (Metric)
25.40
Length of Cut (Fractional)
1
Shank Diameter (Metric)
9.53
Shank Diameter (Fractional)
3/8
Overall Length (Metric)
63.50
Overall Length (Fractional)
2-1/2
Helix Angle
30 degrees
Cutting Diameter (Decimal)
0.3750
Number of Flutes
4
Cutting Diameter (Fractional)
3/8
Shank Diameter (Decimal)
0.3750
Length Type
Standard
Coating/Finish
Uncoated
Coolant Option
External Coolant
Corner Radius (Decimal)
0.0300
Corner Radius (Metric)
0.76
End Type
Corner Radius
Helix Direction
Right
Size System
Fractional
Fullerton Corner Radius End Mill: 3/8" Dia, 1" LOC, 2-1/2" OAL, .030" Corner Radius, 4 Flute, Uncoated, 33721
$53.88
