Harvey Tool Ball End Mill: 1/32" Dia, .025" LOC, 2" OAL, 9/32" Reach, 2 Flute, AlTiN Nano, 773931-C6

Harvey Tool

No reviews yet Write a Review
SKU:
HAR-773931-C6
$83.10

Harvey Tool ball end mill for steel and stainless steel, 2 flutes, 35 degree helix. Solid carbide, AlTiN Nano coating. Manufacturer part number 773931-C6.

Specifications

Unit of Measure
Inch
Cutting Diameter (Decimal)
0.0310
Length of Cut (Decimal)
0.0250
Shank Diameter (Decimal)
0.1875
Overall Length (Decimal)
2.0000
Coating/Finish
AlTiN Nano
Neck Diameter (Decimal)
0.1520
Type
I
Number of Flutes
2
Shank Diameter (Fractional)
3/16
Overall Length (Fractional)
2
Size System
Fractional
Cutting Diameter (Fractional)
1/32
Reach (Decimal)
0.2810
Neck Angle
15
Tapered Reach (Decimal)
0.2500
Tapered Reach (Fractional)
1/4
Cutting Diameter Tolerance (Decimal)
+0.0000/-0.0010
End Type
Ball
Helix Angle
35 degrees
LxD Ratio
0.8xD
Material
Solid Carbide
Reach (Fractional)
9/32
Shank Tolerance
h6
Workpiece Material
Steel, Stainless Steel
Harvey Tool Ball End Mill: 1/32" Dia, .025" LOC, 2" OAL, 9/32" Reach, 2 Flute, AlTiN Nano, 773931-C6
$83.10
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
