Kyocera Turning Insert CCMT3252 CA510: TAA00500

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TAA00500
$22.10

Kyocera Turning Insert CCMT3252 CA510, manufacturer part number TAA00500.

Specifications: IC Size: 3/8 in (9.525 mm); Insert Thickness: 5/32 in (3.97 mm); Corner Radius: 1/32 in (0.80 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8840300; Rake: Positive; Number of Cutting Edges: 2; Cutting Range: Medium; Usage Classification: Continuous; Insert Size: 3252; Hand Direction: Neutral; Insert Style: CCMT; Insert Shape: 80 Degree Diamond; ANSI Designation: CCMT3252CA510; ISO Designation: CCMT09T308; Included Angle: 80 degrees; Machining Operations: Boring, External Turning, Facing, Internal Facing; Insert Grade: CA510; Workpiece Material: Steel; Coating Process: CVD.

Material: Carbide. Coating/Finish: TiCN/Al2O3/TiN. Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Neutral
Material
Carbide
Coating/Finish
TiCN/Al2O3/TiN
Insert Thickness (Metric)
3.97
Corner Radius (Fractional)
1/32
Included Angle
80
ANSI Designation
CCMT3252CA510
Insert Style
CCMT
Machining Operations
Boring, External Turning, Facing, Internal Facing
Insert Shape
80 Degree Diamond
Insert Holding Method
Screw or Clamp
Insert Size
3252
Old Material Number
8840300
Insert Grade
CA510
Workpiece Material
Steel
Rake
Positive
Insert Thickness (Fractional)
5/32
Corner Radius (Metric)
0.80
Number of Cutting Edges
2
Coating Process
CVD
Cutting Range
Medium
Usage Classification
Continuous
IC Size (Metric)
9.525
ISO Designation
CCMT09T308
IC Size (Fractional)
3/8
Pack quantity
10
