Kyocera CNMM 43XRSX PR005S Grade PVD Carbide, Indexable Turning Insert

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TLH10008
$14.53
Kyocera CNMM 43XRSX PR005S Grade PVD Carbide, 0 Degree, Diamond, Negative Rake Angle, Right-Hand Turning Insert for Continuous and Roughing in (S) Heat-Resistant Alloy

Specifications

Series
ISOI
Unit of Measure
Fractional
Cutting Direction
Right-Hand
Material
Carbide
Coating/Finish
PVD
Primary Workpiece Material
(S) Heat-Resistant Alloy
Included Angle
80 degrees
Thickness
3/16 Inch
Style
CNMM
Application
Boring, External Turning, Facing, Internal Facing
Shape
80 Degree Diamond
Insert Holding Method
Screw or Clamp
Size
43
Old Material Number
8858282
ANSI Part Number
CNMM43XRSXPR005S
ISO Part Number
CNMM1204XR-SX
Rake
Negative
Material Group / Grade
PR005S
Number of Cutting Edges
2
Thickness (Metric)
4.76
Chipbreaker
SX
Cutting Range
Roughing
Usage Classification
Continuous
Insert Included Angle
80 degrees
Inscribed Circle (Metric)
12.70
Inscribed Circle
1/2 Inch
Pack quantity
10
PDF 3
https://s3-us-west-2.amazonaws.com/catsy.739/PR005S_PR015S.pdf
Kyocera CNMM 43XRSX PR005S Grade PVD Carbide, Indexable Turning Insert
$14.53
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
