Kyocera CNMU 2421EGK PR1725 Grade PVD Carbide, Indexable Turning Insert

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TLM00102
$22.10
Kyocera CNMU 2421EGK PR1725 Grade PVD Carbide, 0 Degree, Diamond, Negative Rake Angle, Neutral Turning Insert for Light Interruption and Medium-Roughing in (P) Carbon/Alloy Steel and (P) Free-Cutting Steel, (M) Stainless Steel

Specifications

Series
DSSS
Unit of Measure
Imperial
Cutting Direction
Neutral
Material
Carbide
Coating/Finish
PVD
Primary Workpiece Material
(P) Carbon/Alloy Steel
Included Angle
80 degrees
Style
CNMU
Application
External Turning, Facing
Shape
80 Degree Diamond
Insert Holding Method
Screw or Clamp
Size
2421
Old Material Number
8863355
ANSI Part Number
CNMU2421EGKPR1725
ISO Part Number
CNMU070304E-GK
Rake
Negative
Material Group / Grade
PR1725
Corner Radius (Metric)
0.40
Number of Cutting Edges
4
Corner Radius (Fractional)
1/64
Thickness (Fractional)
1/8
Thickness (Metric)
3.18
Chipbreaker
GK
Cutting Range
Medium-Roughing
Usage Classification
Light Interruption
Insert Included Angle
80 degrees
Inscribed Circle (Metric)
7.50
Inscribed Circle
0.30 Inch
Pack quantity
10
PDF 2
https://s3-us-west-2.amazonaws.com/catsy.739/Small_Part_Tooling_Solutions.pdf
Kyocera CNMU 2421EGK PR1725 Grade PVD Carbide, Indexable Turning Insert
$22.10
Add to Your List
Request a Quote

Buying in volume or need custom terms? Request a Quote.
