Kyocera Turning Insert DCMT3252GK CA125P: TMK00368

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TMK00368
$27.04

Kyocera Turning Insert DCMT3252GK CA125P, manufacturer part number TMK00368.

Specifications: IC Size: 3/8 in (9.525 mm); Insert Thickness: 5/32 in (3.97 mm); Corner Radius: 1/32 in (0.80 mm); Insert Holding Method: Screw or Clamp; Rake: Positive; Number of Cutting Edges: 2; Cutting Range: Finishing-Medium; Usage Classification: Continuous to Light Interruption; Insert Size: 3252; Hand Direction: Neutral; Insert Style: DCMT; Insert Shape: 55 Degree Diamond; ANSI Designation: DCMT3252GKCA125P; Chip Breaker Type: GK; ISO Designation: DCMT11T308GK; Included Angle: 55 degrees; Machining Operations: Back Boring, Copying, External Turning; Insert Grade: CA125P; Workpiece Material: Steel; Coating Process: CVD.

Material: Carbide. Coating/Finish: TiCN/Al2O3/TiN. Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Neutral
Material
Carbide
Coating/Finish
TiCN/Al2O3/TiN
Insert Thickness (Metric)
3.97
Corner Radius (Fractional)
1/32
Included Angle
55
ANSI Designation
DCMT3252GKCA125P
Insert Style
DCMT
Machining Operations
Back Boring, Copying, External Turning
Insert Shape
55 Degree Diamond
Insert Holding Method
Screw or Clamp
Insert Size
3252
Insert Grade
CA125P
Workpiece Material
Steel
Rake
Positive
Insert Thickness (Fractional)
5/32
Corner Radius (Metric)
0.80
Number of Cutting Edges
2
Coating Process
CVD
IC Size (Fractional)
3/8
Cutting Range
Finishing-Medium
Usage Classification
Continuous to Light Interruption
IC Size (Metric)
9.525
Chip Breaker Type
GK
ISO Designation
DCMT11T308GK
Pack quantity
10
PDF 1
https://s3-us-west-2.amazonaws.com/catsy.739/CA115P_CA125P_CVD_Coated_Carbide_for_Steel.pdf
