Kyocera Turning Insert DNGA431T00515ME KBN70M: TBJ02212

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TBJ02212
$99.73

Kyocera Turning Insert DNGA431T00515ME KBN70M, manufacturer part number TBJ02212.

Specifications: IC Size: 1/2 in (12.70 mm); Insert Thickness: 3/16 in (4.76 mm); Corner Radius: 1/64 in (0.40 mm); Insert Holding Method: Screw or Clamp; Old Material Number: 8828586; Rake: Negative; Number of Cutting Edges: 2; Cutting Range: Finishing-Medium; Usage Classification: Continuous to Heavy Interruption; Insert Size: 431; Hand Direction: Neutral; Insert Style: DNGA; Insert Shape: 55 Degree Diamond; ANSI Designation: DNGA431T00515MEKBN70M; ISO Designation: DNGA150404T01215ME; Included Angle: 55 degrees; Machining Operations: Boring, Copying, External Turning; Insert Grade: KBN70M; Coating Process: PVD.

Material: CBN. Coating/Finish: MEGACOAT. Series: ISOI. Unit of measure: Inch.

Specifications

Series
ISOI
Unit of Measure
Inch
Hand Direction
Neutral
Material
CBN
Coating/Finish
MEGACOAT
Insert Thickness (Fractional)
3/16
Corner Radius (Fractional)
1/64
Included Angle
55
ANSI Designation
DNGA431T00515MEKBN70M
Insert Style
DNGA
Insert Thickness (Metric)
4.76
Insert Shape
55 Degree Diamond
Insert Holding Method
Screw or Clamp
Insert Size
431
Old Material Number
8828586
Machining Operations
Boring, Copying, External Turning
Insert Grade
KBN70M
Rake
Negative
IC Size (Metric)
12.70
Corner Radius (Metric)
0.40
Number of Cutting Edges
2
Coating Process
PVD
Cutting Range
Finishing-Medium
Usage Classification
Continuous to Heavy Interruption
IC Size (Fractional)
1/2
ISO Designation
DNGA150404T01215ME
