Kyocera DPET 32501FRUSF PR930 Grade PVD Carbide, Indexable Turning Insert

Kyocera Precision Tools

No reviews yet Write a Review
SKU:
KYP-TKT00473
$41.06
Kyocera DPET 32501FRUSF PR930 Grade PVD Carbide, 11 Degree, Diamond, Positive Rake Angle, Right-Hand Turning Insert for Light Interruption and Finishing in (P) Carbon/Alloy Steel and (M) Stainless Steel

Specifications

Series
ISOI
Unit of Measure
Fractional
Cutting Direction
Right-Hand
Material
Carbide
Coating/Finish
PVD
Primary Workpiece Material
(P) Carbon/Alloy Steel
Included Angle
55 degrees
Thickness
5/32 Inch
Style
DPET
Application
Copying, External Turning
Shape
55 Degree Diamond
Insert Holding Method
Screw or Clamp
Size
32501
Old Material Number
8810379
ANSI Part Number
DPET32501FRUSFPR930
ISO Part Number
DPET11T3003FR-USF
Rake
Positive
Material Group / Grade
PR930
Corner Radius (Metric)
0.03
Number of Cutting Edges
2
Thickness (Metric)
3.97
Chipbreaker
USF
Cutting Range
Finishing
Usage Classification
Light Interruption
Insert Included Angle
55 degrees
Inscribed Circle (Metric)
9.53
Inscribed Circle
3/8 Inch
Pack quantity
10
Kyocera DPET 32501FRUSF PR930 Grade PVD Carbide, Indexable Turning Insert
$41.06
