Primary Workpiece Material
(P) Steel
Corner Radius (Metric)
0.20
Inscribed Circle (Metric)
9.53
Cutting Width (Decimal)
0.06
Application
External Grooving
Thickness (Fractional)
1/8
Insert Holding Method
Screw or Clamp
Old Material Number
8836734
ANSI Part Number
GBA32R150020PV7040
ISO Part Number
GBA32R150-020
Number of Cutting Edges
3
Usage Classification
Continuous
Corner Radius (Decimal)
0.01
Cutting Width Minimum (Decimal)
0.06
Cutting Width Minimum (Metric)
1.50
Cutting Width Maximum (Decimal)
0.06
Cutting Width Maximum (Metric)
1.50
Max Depth of Cut (Decimal)
0.08
Max Depth of Cut (Metric)
2
Inscribed Circle (Fractional)
3/8
